ULTIMATE V-RAKE RMT PARTS LIST
UPRIGHT POST & POSITIONING WHEEL ASSEMBLY, RIGHT HAND SIDE
Ref. Part No. Description Qty.
1 ULT2070R Leg with Bushing, Right Hand Middle, no hubs or spindles 1
2 ULT2090 Hinge, Leg Half, Right Hand 1
3 ULT2080 Hinge, Wing Half 1
4 ULT2081 Pin, 14-3/4” Wing to Leg Mount 1
5 ULT2015 Pin Kit for Small Clevis on Platform 1
6 50N200WFH0Z Washer, 1/2” x 2” Fender Heavy Steel 1
7 50NLOC0Z Washer, 1/2” Lock 1
8 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 1
9 PSW-2202-64BX Bushing, 2-1/2” x 2-1/4” x 3” Bronze 4
10 ULT20891 Retainer, Hinge Leg Mount 1
11 ULT20801 Retainer, Hinge Wing Mount 1
12 75C300HCS5Z Bolt, 3/4”-10 x 3” HHC G5 6
13 ULT20802 Washer, Wing Mount Retainer 1
14 75NLOC0Z Washer, 3/4” Lock 10
15 75CNFH5Z Nut, 3/4”-10 G5 10
16
17 37CNNE0Z/NE Nut, 3/8”-16 Lock 1
18 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 1
19
20 ULT20701 Clamp, Hose 5” ULT Middle Leg 2
21 ULT20702 Linkage, Wing Adjustment Cylinder 1
22 PSW-1001-64 Bushing, 1” x 1-1/4” x 1” Bronze 2
23 HD2758 Cylinder, 2-3/4” x 8” 1
24 1503-8-8 Street Elbow, 1/2” 45 Deg. With Swivel 2
25 844905048-BX Hydraulic Hose, 1/2” 48” 2-Wire 2
26
27 8449050120-BX Hydraulic Hose, 1/2” 120” 2-Wire 1
28 ULT6010 Cylinder Pin, Transport 2
29 111-20 Hair Pin Clip, #6 2
30 100N150AMB0/10G Washer, 1” x 1-1/2” x 10 GA AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14 GA AR
31 18R200PC00Z Cotter Key, 3/16” x 2” 2
32 ULT6030 Transport Bar, Lower 1
33 ULT20711 Spindle Assembly, Middle (Dual) 1
34 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 4
35 RM-2115 Pin, 1” x 6-1/2” Hinge Mount 1
36 31R150PSP0/HBK Roll Pin, 5/16” x 1-1/2” Spiral 1
37 CR20148 Seal, 803 Hub 1
38 25590 Cone, Inner 803 Hub 1
39 25520 Cup, Inner 803 Hub 1
40 2805810 Hub, 803 without Bearings 1
W 803 Hub, 803 Assembly, Complete with Bearings 1
41 25821 Cup, Outer 803 Hub 1
42 25877 Cone, Outer 803 Hub 1
43 FH107912 Washer, 803 Hub 1
44 9129521 Nut, Slotted 803 Hub 1
45 909982 Cap, Hub 803 1
46 15R175PCO0Z Cotter Key, 5/32” x 1-3/4” 1
47 845501115 Tire, 11L x 15” Implement 1
48 150806W35 Rim, 15 x 8 x 6 Bolt 1
49 913538 Bolt, 9/16” x 1-1/2”, Lug 803 Hub 8
50 SS-96104-48 Bearing, 3” x 3-1/4” x 3” Bronze 2
51 ULT1011A Retainer Plate, 1/2” PL x 4” Circle 2 Holes, Leg Top 1
52 107-100 Zerk, 1/4”-28 Str. Lub 6
53 111-100 Zerk, 1/4”-28 90 Deg NFT 1
AR=As Required
