ULTIMATE V-RAKE RMT PARTS LIST
UPRIGHT POST & POSITIONING WHEEL ASSEMBLY, LEFT HAND SIDE
Ref. Part No. Description Qty.
1 ULT2070L Leg, Middle, Left Hand 1
2 ULT2089 Hinge, Leg Half, Left Hand 1
3 ULT2080 Hinge, Wing Half 1
4 ULT2081 Pin, Hinge, 14-3/4” Wing to Leg Mount 1
5 ULT2015 Pin Kit for Small Clevis on Platform 1
6 50N200WFH0Z Washer, 1/2” x 2” Fender 1
7 50NLOC0Z Washer, 1/2” Lock 1
8 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 1
9 PSW-2202-64BX Bushing, 2-1/2” x 2-1/4” x 3” Bronze 4
10 ULT20891 Retainer, Hinge, Leg Mount 1
11 ULT20801 Retainer, Hinge, Wing Mount 1
12 75C300HCS5Z Bolt, 3/4”-10 x 3” HHC G5 6
13 ULT20802 Washer, Wing Mount Retainer 1
14 75NLOC0Z Washer, 3/4” Lock 10
15 75CNFH5Z Nut, 3/4”-10 G5 10
16
17 37CNNF0Z/NE Nut, 3/8”-16 Lock 1
18 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 1
19
20 ULT20701 Clamp, Hose 2
21 ULT20702 Linkage, Wing Adjustment Cylinder 1
22 PSW-1001-64 Bushing, 1” x 1-1/4” x 1” Bronze 2
23 HD3258 Cylinder, 3-1/4” x 8” 1
24 1503-8-8 Street Elbow, 1/2” 45 Deg. With Swivel 2
25 844905048-BX Hydraulic Hose, 1/2” x 48” 2-Wire 2
26
27 844905120-BX Hydraulic Hose, 1/2” x 120” 2-Wire 1
28 ULT6010 Pin, Transport Cylinder 2
29 111-20 Hair Pin Clip #6 2
30 100N150AMB0/10G Washer, 1” x 1-1/2” x 10GA AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14GA AR
31 18R200PC00Z Cotter Key, 3/16” x 2” 2
32 ULT6030 Transport Bar, Lower 1
33 ULT20711 Spindle Assembly, Middle Dual, 803 without Hub 1
34 RM-2115 Pin, 1” x 6-1/2” Hinge Mount 1
35 31R150PSP0/HBK Roll Pin, 5/16” x 1-1/2” Spiral 1
36 SS-96104-48 Bushing, 3” x 3-1/4” x 3” Bronze 2
37 ULT1011A Retainer, Leg Top, 2 Holes 1
AR=As Required
