ULTIMATE V-RAKE RMT PARTS LIST
RAKING WHEEL & RAKING ARM ASSEMBLY
Ref. Part No. Description Qty. Per Wheel Assembly
1 WR5900 Wheel, Bare RMT, 19 Tooth, White 1
WR7900 Wheel, Bare RMT, 24 Tooth, Red 1
2 WR5901 Tooth, Double Rubber Mounted, For White Wheel 19
WR5904 Tooth, Double Rubber Mounted, For Red Wheel 24
3 37NUSS0Z Washer, 3/8” Flat 8
4 37C100HCS5Z Bolt, 3/8”-16 x 1” HHC G5 27
4A 37C100BFL5Z Bolt, 3/8"-16 x 1" Flange Bol 19 or 24
5 WR5905 Poly Plate, RMT 1
6 WR6023 Poly Kit with Fasteners 1
7 WR6051L Wheel Assembly, 19 Tooth Complete with Poly and Fasteners LEFT 1
WR6051R Wheel Assembly, 19 Tooth Complete with Poly and Fasteners RIGHT 1
WR7051L Wheel Assembly, 24 Tooth Complete with Poly and Fasteners LEFT 1
WR7051R Wheel Assembly, 24 Tooth Complete with Poly and Fasteners RIGHT 1
8 37CNNE0Z/NE Nut, 3/8” Lock 27
9 43C125HCS5Z Bolt, 7/16”-14 x 1-1/4” HHC G5 6
10 43CNNE0Z/NE Nut, 7/16”-14 Lock 6
11 WR6022 Spindle and Plate 1
12
13 WR4928RMT* Arm with Boxings, Lift Compression Spring *Designate Left or Right 1
14 WR150130 Spindle, 1-1/2” x 11-1/2” RMT - Tapped 1
15 15234VB Seal, Rake Tine Wheel 1
16 LM67048 Cone, Tapered Roller Bearing 2
17 LM67010 Cup, Tapered Roller 2
18 9136831 Washer, W888 2
19 15R125PCO0Z Cotter Key, 5/32” x 1-1/4” 2
20 9129521 Nut, Slotted 2
21 001601 Cap, Grease 2
