ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-19
GRAPH WITH MAXIMUM LENGTHS - MODEL 75
0 3 6 2730333639424548
1
2
3
4
5
6
(m)
7
H
(m)
MAX. 75
FIGURE 21.
3m max.
L
9 51 54 57 60
L
12 15 18 21 24
A b
Max.
3m.
Min.1,5m
Thefirstextraelbow(45) reduces the maximum length with 3 meters. The followiing extra elbows with 4,5 m.
All lengths within the graph are allowed. If dimentions pass the graph limits, use an extention boot, and consider the system as two separate
Flex-Augers Model 75
For return tandem
