ROXELL - 031 - 0516
FLEX-AUGER - COMPONENTS
II-15
EXTENSION BOOT FA 55 - 03501350
Key Name Part Nr. Qt.
1 CONTROL UNIT FA55 WITHOUT DROP 13502182 1
1.1 HOUSING - CONTROL UNIT Ø56 13502166 1
1.2 WINDOW 13000500 1
1.3 THREAD FORMING SCREW 4X12-A2 12502043 1
1.4 REINFORCEMENT PLATE Ø56-75-90-MOTOR 13109046 1
1.5 SWITCH PLATE WITH PRESS SCREW 13109533 1
1.6 ADHESIVE TAPE 19X0.23-2SIDE 30800726 2
1.7 MINIMUM SWITCH SHIELD 10203115 1
1.8 SWITCH CONNECTION STRIP 13105259 1
1.9 PARCKER SCREW 8X1/2" 20100525 2
1.10 PARCKER SCREW 4.2X16 - DIN 7981 20102331 2
1.11 HANDY BOX IPW AX4-IP55 15009814 1
1.12 NUT M4 20100681 2
1.13 HARDWARE KIT CU FA 55 13502208 1
1.13.1 DRIVE BLOCK 10100782 1
1.13.2 GALV.WASHER Ø39X23X3 20103842 1
1.13.3 DRIVE TUBE 13500434 1
1.13.4 BOLT M8X20 - DIN 933-8.8 20200150 4
1.13.5 SOCKET CAP SCREW M6X35 DIN 912 20102158 1
1.14 WASHER 5.3X10X1 - DIN 125 - A2 20102315 2
1.15 CLAMP STROKE 27 20 6E/3 10103109 1
1.16 TUBE CLAMP ASSEMBLY Ø67MM 03501293 1
1.17 SAFETY SWITCH ASS'Y 13104567 1
2 BOOT ASS'Y FA55 FOR EXT.BOOT 13502190 1
2.1 INTAKE BOOT & CLOSING PLATE 13502257 1
2.1.1 BOOT BODY WELDMENT FA 55 13501515 1
2.1.2 GASKET 15X2 30800874 1
2.1.3 CLOSING PLATE 13107776 1
2.1.4 FIBER RING 20104287 1
2.1.5 NUT M10 - DIN 934 20100277 1
2.1.6 CLOSING PROFILE 13107768 1
2.1.7 CLOSING BOLT - BRASS SMAL 13108154 1
2.1.8 DECAL - HANDS WARNING 13106596 1
2.1.9 ROXELL DECAL - 160X40 10101129 1
2.1.10 E-RING Ø5-DIN 6799-A2 S.S 20102018 1
2.1.11 HARDWARE KIT EXTENSION BOOT 13000526 1
2.1.11.1 BOLT M8X20 - DIN 933-8.8 20200150 4
2.1.11.2 NUT M8 DIN 934 - SP 20200119 4
2.1.11.3 SEAL CAP M8 16103699 4
2.1.11.4 KNURLED KNOB 13107842 1
2.2 ANCHOR & BEARING ASS'Y FA55 13502307 1
2.2.1 BEARING 17X35X10 - 6003 LLU 13201066 1
2.2.2. SEEGER RING Ø17X1 20101333 1
2.2.3 BOLT M6X12 - DIN 933-8.8 20100160 2
2.2.4 LOCKNUT M6 - DIN 985 20100400 2
2.2.5 SHAFT WELDMENT 13502281 1
2.2.6 BEARING HOLDER CAP UP - Ø56 13502265 1
2.2.7 BEARING HOLDER CAP DOWN - Ø56 13502273 1
2.2.8 TUBE CLAMP ASS'Y Ø63 13601661 1
3 EXTENSION PLATE Ø160 GALVANISED 13109525 1
4 HW KIT FOR FA EXTENSION 360° 13000518 1
4.1 LOCKNUT M6-DIN 985-A2 20101960 4
4.2 BUT.HEAD CAP SCREW WITH FLANGE M6X16
20109146 4
5 DROP Ø160 FOR EXTENSION BOOT 13000492 1
