Roxell FLEX-AUGER FA 55 - Page 163

ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-65
FLEX-AUGER FEED MIX
FIGURE 129.
Outlet 125
Tube Mod. 125
Tube Mod. 90
Auger : Mod 90
FA II = FA75
FA I = FA90
Auger : mod 90
TO INSTALL FLEX AUGER I : SEE GENERAL INSTALLATIONS FLEX AUGER 90/125.
SPECIAL REMARKS :
FIGURE 130.
1. Always install the Flex-Auger Mix intake boot horizontally, never under an angle.
FIGURE 131.
