HANDLEBAR & CONTROL LAYOUT
LEFT HANDLE BAR
Engine Stop Switch: With this switch in the “RUN” position, the engine can be
started. The engine will not start with this switch in the “OFF” position.
Start Button: When the ignition key is in and turned to the “ON” position, the Engine
Stop Switch is in the “RUN” position, this Button will start the engine.
Rear Hydraulic Brake Apply the rear brake by squeezing the rear brake lever
towards the grip.
Headlight Switch This switch controls the operation of the headlights. Available
positions are “HI” and “LO”.
Rear Parking Brake Activate the rear parking brake by squeezing Rear brake lever c
and then moving the lock plate e into position to lock Rear brake lever c into place.
