DRIVING CHAIN CLEAN AND OILING
If you find any of these problems with your sprocket, consult Ricky Power Sports LLC or
your local service center.
DRIVE CHAIN CLEANING AND OILING
Clean and oil the chain as the following:
Steam cleaning, high-pressure washers, and certain solvents can damage the drive chain.
Use only kerosene to clean the chain. Wipe it dry, and thoroughly lubricate it with SAE 30~50
motor oil. Do not use any other lubricants on the drive chain.
Adjusting the Drive Chain
10~20 mm (0.39~0.79 in)
The drive chain should be adjusted while all four tires are on the ground and make sure
there is 10~20 mm (0.39 ~ 0.79 in) of slack, as shown above. If the vertical
deflection exceeds 20mm (0.79 in), adjust the chain slack.
