1. Enter software and log in with the applicable credentials.
2. Go to Maintenance and select 'RPI"
3. Press Replace vent filter, the following message is given:
4. Press YES to confirm and start actual replacement.
5. Press YES after the message "Instrument will be offline."
6. Remove the top panel by loosening (with Torx T10) the three M4 bolts at the back, lifting up and fully
removing from the instrument.
a.Unscrew the old filter,
b.Check O-ring
c.Replace it with a new filter.
If no other actions is needed:
7. Place top panel and fasten with the three bolts.
Maintenance
76
MRN-184-EN Version 6 (05-01-2022)
