F72 Error: Expiration date of manual
barcode has already passed
Placed concentrate is out of
date
Replace cubitainer with correct
expiration date
F73 An unexpected error has occurred in the
tagreader
NFC reader failure Call for service
F74 Tag is write protected and cannot be
used
Unusable tag on place
cubitainer
Replace cubitainer with a writable tag
F75 Maintenance: Cleaning procedure is
required
Call for service
F76 Maintenance: Replace the cubitainer
pickup tubes
LT: Replace Cubitainer pickup tubes
F77 Maintenance: Replace the peristaltic
pump tubes.
LT: Replace the peristaltic pump
tubes.
F78 Maintenance: Replace the endpoint
filters
LT: Replace endpoint filters
F79 Maintenance: Replace the vent filter LT: Replace vent filter
F80 Maintenance: Annual maintenance is
required
Annual maintenance is due, please
contact your service engineer
Error list
MRN-184-EN Version 6 (05-01-2022)
93
