RSG MCS-16 - H: Handset Specification; H:1 Universal Multi-Way Mini Handset - 8 Buttons (MCS-T8)

H:1 Universal Multi-Way Mini Handset - 8 Buttons (MCS-T8)
Switch No. Legend (eg Front Spots) Colour PTT L M
1
2
3
4
5
6
7
8
H:2 Universal Multi-Way Mini Handset - 7 Buttons (MCS-T8)
Switch No. Legend (eg Front Spots) Colour PTT L M
1
3
4
5
6
7
8
RSG Engineering Limited Telephone : 01543 438800 Fax : 01543 438801 Email : sales@rsg-ontop.com Web : www.rsg-ontop.com
1:16
UNIVERSAL CONTROLLER LITE (MCS-16) USER GUIDE V1 H : HANDSET AND SWITCH UNIT SPECIFICATION
H : Handset Specification
Please Note:
Any key can be programmed for use as PTT (Push To Talk), please tick the box next to the appropriate key number if required.
L = Latching M = Momentary, please tick the box next to the appropriate key number if required.
The key colour is created by the LED shining behind the key, please specify the colour required.
Keep words as short as possible and abbreviate long words, if an abbreviation is not stated we will insert a standard abbreviation.
Cable entry and button numbering will remain in the same position regardless of the handset orientation.
