UNIVERSAL CONTROLLER LITE (MCS-16) USER GUIDE V1 E : PRODUCT SPECIFICATION
E : Product Specification
Product Overview
The Universal Controller Lite (MCS-16) consists of a main
control box which contains everything required to control a
vehicle mounted hazard warning system, typically comprising
rooftop lighting, secondary hazard warning lights and audio
equipment. It has 16 outputs and 16 standard inputs with
power management functions including run lock, split charging,
load shedding and headlight flash, plus many more, some of
which may be implemented via the vehicle CAN Bus system.
It also includes a logic switch module to facilitate the control
of auxiliary add-on devices such as: Gateway Radio Controller,
Audio Interface Controller (Intercom with pre-recorded
‘voice’ alerts) and Fan Controller.
Operate the controller through one of our range of fully compatible
hand held or dash mounted switch units and you have an economical
hazard warning control system that does not compromise on features
or functionality.
System Intelligence
The main control unit is supplied with default settings that will suit
a variety of applications, however it can be simply customised
to match the end users specific application by plugging in to a
laptop/desktop PC and utilising the ‘easy to use’ complimentary
software.
Human Machine Interface (HMI)
We have developed a collection of switch units specifically designed
to interface with the Universal Controller Plus (MCS-32). They range
from a 7-way handset through to a 16-way flush/DIN mount unit,
with every conceivable combination in between. Handsets have
the facility to operate a Public Address (PA) system via an integral
microphone and the option to allocate any button to operate
the Push to Talk (PTT) feature. Full details are given later in this
catalogue.
One Source, One Solution
In order to simplify the installation process each unit is supplied
fully loaded with all the necessary features and functions to
implement a comprehensive system. Simply enable the required
function via the ‘easy to use’ software.
Logic Functions
An abundance of logic functions means complex applications are no
longer difficult to implement, particularly where certain operations
are interlinked with others. So, carrying out ‘and/or’ functions and
implementing ‘do this when’ or ‘stop this when’ are simple to apply
together with the facility to alter functions allowing continual client
synchronisation.
System Configuration
This is a simple 3-stage process which entails enabling and labelling
inputs and outputs, configuring the system operation and down-
loading the application onto the unit. This operation need only be
done once, when completed it can be simply be transferred onto
other units via a laptop.
Software Operational
Modules
100 WATT SIREN
• Supports 8 or 11 ohm speakers
• Can be enabled from an input or handset
• Air horn input
• HRT positive or negative activation
• Multiple siren tones selected from software
• Monitor signal active when siren on
•PA
• UK and European sounds
• City Mode volume reduction feature
• Workshop mode volume suppression feature
for testing
• Can be linked with other MCS siren devices
to give two vehicle effect
LOAD SHEDDING MODULE
• Via internal or external monitoring
• Automatic in conjunction with other
equipment activation
FAN CONTROL MODULE
• Control up to 4 intake/extractor fans
• Reverses power supply to fans
• Optional 4-way relay expansion module
SALOON LIGHTING MODULE
• Ideal to control internal ambulance lighting
• Manual, semi and full automatic operation
CABINET ANTI-TAMPER MODULE
• Monitor 16 ambulance medical lockers
• Ideal for monitoring medical
consumables/medicines
• Cabinet re-stock indication
AUDIO INTERCOM CONTROLLER
(operates with external device)
• Announce pre-recorded messages
• Duplex or simplex intercom
SPLIT CHARGE CONTROLLER
• Monitors primary battery voltage
• Output drives charging solenoid to charge
secondary battery
• Solenoid in and out voltage programmable
RUN LOCK CONTROLLER
• Outputs
- 1 dedicated runlock outputs
- Additional outputs assigned from software
• Enable Inputs
- Inputs assigned in software
- From handset, handbrake, remote button etc.
- Hi or Lo inputs
• Reset Inputs
- Inputs assigned in software
- From brake light, remote button etc.
- Hi or Lo inputs
HEADLIGHT FLASH
• Dedicated outputs x 2 (with built-in diodes)
to control headlights and/or complementary
flashing lamps
GATEWAY RADIO CONTROLLER
• Automatically switches between the Main
& Gateway Radio (for built-up areas) within
a 30 second window for the driver to exit
the vehicle
• Automatic handbrake detection
ADDITIONAL FEATURES
• 16 x AND logic modules
• 16 x OR logic modules
• 32 x timer modules
General Features
and Functions
OUTPUTS
16 Outputs:
• 8 Hi Power Outputs
- 20 Amps per channel
(40 Amps total)
- Current limiting
- Multi flash patterns
- Timer shutdown
- Voltage drop out
• 4 Low Power Outputs
- 600mA per channel
- Positive & negative polarity
switching
- Provide monitoring signal inputs
- Negative polarity to switch low
power relay
• 4 Medium Power Outputs
- 2.5 Amps per channel
- Positive & Negative polarity
switching
- Provide monitoring signal inputs
- Drive relays
- Small motors
• 2 diode pairs built in for
headlight and/or tail light flashers
• Output to data logger
• Electronic Fuses
- Electronically adjustable
- Electronically tripped
INPUTS
• 16 Configurable Inputs
- 8 negative switching
- 8 positive switching
- Software configurable
- External reset
- Standby input
• 3 Standard Inputs
- Mic input
- Reset
- Standby
MULTI-WAY SWITCH OPTIONS
• Universal Multi-Way handset can
be fully configured using the MCS
software
• Single or up to 4 handsets
SERIAL DATA PORT
• USB x 1
• Link with third party MDT terminals
CAN OR CAN TYPE DATA PORT
• Link to RSG complementary devices
such as a lightbar
• Link to other industry new standard
devices
• Link with legacy equipment - PWM
USER INTERFACE
• 24 illuminated status indicators
• Indicates flash pattern
• Communication status
• Provides output status
• Green - OK
• Red - Over current
• Amber - Low voltage
SPECIFICATION
• Dual voltage
• 100 Amps total output
• Spec 5 approved
• 12v version only e-approved
