UNIVERSAL CONTROLLER LITE (MCS-16) USER GUIDE V1 J : HANDSET AND SWITCH UNIT OPTIONS
J : Switch Unit Specification
Please Note:
L = Latching M = Momentary, please tick the box next to the appropriate key number if required.
The key colour is created by the LED shining behind the key, please specify the colour required.
Keep words as short as possible and abbreviate long words, if an abbreviation is not stated we will insert a standard abbreviation.
Cable entry and button numbering will remain in the same position regardless of orientation please tick the appropriate box to specify
cable entry.
One Box Single Vehicle Architecture (OBSVA) Solution compatible.
1 Large + 4 Small Buttons - Vertical (MCS-F5)
Switch No. Legend (eg Front Spots) Colour L M
1
2
3
4
5
CABLE ENTRY BOTTOM
CABLE ENTRY TOP
I require cable entry from the BOTTOM I require cable entry from the TOP
Switch No. Legend (eg Front Spots) Colour L M
1
2
3
4
5
CABLE ENTRY RIGHT CABLE ENTRY LEFT
I require cable entry on the RIGHT I require cable entry on the LEFT
J:2 Universal Multi-Way Slimline Flush Fit Switch Unit
1 Large Button + 4 Small Buttons - Horizontal
(MCS-F5)
To Next Page
