Default IP Address – 192.168.0.100
460 Gateway User Manual Page 56
Note: If the web page does not display, check the following settings:
The web page does not display when the computer is on a wireless network because
of subnet selections. Use either the crossover cable or a hub/switch on the same
subnet.
Verify that your web browser is not set for a proxy server. If you are using Internet
Explorer, check Internet Options/Connections/LAN Settings. Make sure the check
box is checked for Automatically detect settings and the check box is empty (not
checked) next to the Use a proxy server for your LAN option.
Figure 3-1 460 Gateway Main Page
5. Click on
The RTA 460 Device Summary and Status screen displays. See Figure 3-2.
Status and Summary
