Default IP Address – 192.168.0.100
460 Gateway User Manual Page 30
Figure 2-36 EtherNet/IP Server Configuration
DeviceNetMasterconfiguration
If your version of the 460 Gateway requires your gateway to act as a DeviceNet Master, use the
following steps to configure the gateway. At least two Communication Modules must be
configured.
1. Click on next to the
Selected Communication Modules on the RTA 460 Gateway
Main Page. See Figure 2-2.
The
Communication Module Configuration screen displays. See Figure 2-37.
Note: The Edit buttons are grayed out when the task applies to a different 460
Gateway version than you purchased. Please contact Real Time
Automation, Inc. (RTA) at 262.439.4999 or www.rtaautomation.com for more
information about 460 Gateway configurations.
Edit
To Next Page
