Digitaler Stellungsregler
Digital positioner
Positionneur digital
REpos-8010
19.10.2017 REpos-8010.docx Technische Änderungen vorbehalten / Technical changes reserved / Modifications techniques sous réserve page 42
optional
Fix feedback module
4x screw 3x6 self-cutting(TX10)
Connect pre adjusted feedback potentiometer.
Yellow wireterminal 61
Grey wire terminal 62
Red wire terminal 63
Connect positioner output with actuator.
Grey wire terminal K4 to terminal A1
Red wire terminal K5 to terminal A2
Yellow wire terminal K6 to terminal A3
