J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
61 V1.032818
3. Place the corresponding gasket on the coupling side impeller nut.
Figure 8.3. Placing the corresponding gasket in the coupling side impeller nut.
4. Insert the coupling side impeller nut into the shaft until it reaches the impeller. It is inserted
from the coupling side.
Figure 8.4. Inserting the coupling side impeller nut into the shaft until it reaches the impeller.
Lubricate with grease or oil the inner diameter of the impeller nut and the outer
diameter of the shaft.
