J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
62 V1.032818
5. Place the corresponding gasket on the non-coupling side impeller nut.
Figure 8.5. Placing the corresponding gasket on the non-coupling side impeller nut.
6. Insert the impeller nut into the shaft from the non-coupling side until it reaches the impeller.
Figure 8.6. Inserting the non-coupling side impeller nut into the shaft.
Lubricate with grease or oil the inner diameter of the impeller nut and the outer
diameter of the shaft.
