J Line Pump
Horizontal Double Suction Centrifugal Pump ā API 610 Process Pump
69 V1.032818
19. Insert the studs to join the casing cover to the case.
Figure 8.19. Inserting the studs to join the casing cover to the case.
20. Manually place and tighten the hex nuts over the studs place on the previous step to secure
the casing cover to the case.
Figure 8.20. Placing and tightening the hex nuts on the studs to secure the casing cover to the case.
