J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
79 V1.032818
38. Insert the radial oil ring over the shaft from the coupling side inside the radial bearing
housing until it rests on the radial bearing sleeve’s groove.
Figure 8.38. Inserting the radial oil ring over the shaft into the radial bearing housing from the coupling side.
39. Place the corresponding gasket on the external radial bearing housingcover
Figure 8.39. Placing the corresponding gasket on the external radial bearing housing cover.
