J Line Pump
Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
87 V1.032818
53. Bend one of the tabs of the axial bearing lock washer towards one of the grooves of the axial
bearing locknut.
Figure 8.52. Bending one of the tabs of the axial bearing lock washer towards one of the grooves of the axial
bearing locknut.
In search of a match between a tab of the non-coupling side (axial) bearing lock
washer and a slot of the non-coupling side (axial) bearing lock nut, the lock nut
should always move forward, never backwards.
