声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
33
setting. Press and hold the button and power on to restore the factory default
settings, press and hold the button and power on to restore the factory
calibration value, press and hold and power on to enter the boot mode.
1.4.2.1 Main Page Output Voltage and Current Setting
Output voltage and current setting operation video：
https://youtu.be/C3qL3OIkNBo
At the main page, you can press the ON/OFF key to turn on or turn off the
output, when the output is turned on, the ON/OFF key shows in green.
Press button to set the AK: output current value, you can rotate rotary
knob to adjust the output value, press the rotary knob to move the cursor.
Press button to set the AL: output voltage value, the operation way is
similar to output current setting.
Press and hold button to set the AI: over-current protection value; Press
and hold button to set the AJ: over-voltage protection value. The operation
way is similar to output current setting. If you want to set the over-current auto shut
down function, your AI: over-current value should be higher than the AK: Current
setting value.
When the device is under constant voltage mode, it will show
at AE:
Constant voltage Constant current status indicator
, and it will show when under
constant current mode; when the device works normally it will show at AF:
protection status indication, when the AB: actual output current value is higher
than the AI: over-current protection value(OCP), the output will be cut off
automatically, and show , when the AA: actual output voltage value is higher
than the AJ: over-voltage protection value(OVP), the output will be cut off
automatically, and show , when the system temperature is higher than 80℃, the
output will be cut off automatically, and show .
1.4.2.2 Data Group Quick Store and Recall
Data group quick store and recall operation video：
https://youtu.be/7bW9UcJY17o
