RuiDeng RK6006-C User Manual

声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
36
Interface is set to USB by factory default, shows at AN:
Communication interface icon, you can also set it to
Bluetooth/TTL/RS485, USB means the F: Micro USB Port, you
can see at AN: Communication interface icon on the top
when set it USB,
and when the communication starts, it will show ;
You need to insert a Bluetooth board to use the Bluetooth
function, and it will show at AN: Communication
interface icon on the top, and when the communication
starts, it will show ; TTL and RS485 is not available now;
Address is set to 001 by default, you can set it between
001 and 255;
The Baud rate and address on the device should be same
with the information on PC software or APP. You can see
more communication at PC software and APP section in the
manual.
1.4.2.4 Main Page Display Style Setting
Main interface display style setting operation video:
https://youtu.be/kpFtPQGhBmc
You can press to enter the system setting menu,
then press rotary knob and it will be switched to Layout
menu(as shown in figure 6): you can press down arrow key to
enter the Layout sub-menu.
Layout Sub-menu:
Digits Style is set to NORM by default, you can rotate the rotary knob and select
NORM, Seg1 and Seg2(as shown in figure 7).
Press down arrow key to the Custom Colors page.
Custom Colors(figure 8,9):
You can set the the display colors for output voltage, output current, output
power.....as shown in figure 8 and figure 9. After change the color, you need to turn
on the Custom Colors option to apply the settings(as shown in figure 9).
Figure 6
Figure 7
Figure 8
Figure 9
Cust om Col ors
Temper at ur e
Wh
Ah
OCP
OVP
24°C
Cust om Col or s
