Chinese, French, Germany and Russian language;
Take Out is set to OFF by factory default, when recall a
data group, it will keep the previous output status, when set
it ON, it will output directly whe
n recall a data group.
Boot Power is set to OFF by factory default, when boot
the device the output is cut off, when set it on, it will
automatically turn on the output after booting.
Boot Logo is set to ON by factory default, when boot the
device, it will show the boot logo first, then enter the main
interface, when set it OFF, it will enter the main interface
directly.
Buzzer is set to ON by factory default,it will show
on the top at AP: Beeper ON/OFF status icon, and you can
hear the beep when press the button. When set it OFF, it will
show at AP: Beeper ON/OFF status icon, there will not
be beep when press the button.
Backlight is set to level 4 by factory default, it can be set
between level 0-5.
Update Rate is set to Low by factory default, you can set it
S(low)/M(middle)/H(high), it is the fresh rate of the real output voltage and current.
Max Power is set to 380W by factory default, you can set it between 0-380W, it
is the max output power. The max output is default voltage priority mode, when the
setting voltage*setting current is higher than the max power, the device will
automatically decrease the output current setting value. When used together with
low power power source, it is recommended to set the value as the rated power of
the power source*95%.
Temperature unit is ℃ by factory default, it can be switched between ℃ and ℉.
Rotate is set to 0 by factory default, you can set it to 0, 90, 180, 270, after setting,
reboot the device, the display will rotate.
Communication Sub-menu(figure 5):
C
。
Rot at e
Temper at ur e
Max Power
Updat e Rat e
Backl i ght
Buzzer
S
Set t i ngs
24°C
4
0
380W
