Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
PoE overload LED
PoE-max
Off
The overall PoE output does not reach the
maximum power.
Solid green
The overall PoE output reaches the maximum
power.
RJ45 port status LED
Link/Act
(1-24, 25, 26/26F)
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or sending traffic at
10/100/1000 Mbps.
RJ45 PoE status LED
PoE (1-24)
Off
PoE does not supply power.
Solid green
PoE is operational.
1.3 RG-ES110D-P
Technical Specifications
Model
RG-ES110D-P
Ports
8 10/100Base-TX auto-sensing Ethernet ports (Auto MDI/MDIX), and support PoE/PoE+
2 10/100/1000Base-T auto-sensing Ethernet ports (Auto MDI/MDIX)
Power Supply
 AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
Frequency: 50/60 Hz
Rated current: 1.6 A
 Adapter output
Rated voltage range: 53.5 VDC
Rated current range: 2.24 A
EEE
Port 1-8: Supported
Port 9-10: Not Supported
PoE
Support PoE and PoE+.
Ports 1-8 are PoE/PoE+-capable with the maximum power output of 30W per port. Ports 9-10
do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 110W.
Power
Consumption
Less than 8W with no PoE load
Less than 129W with PoE full load
Operating
Temperature
0℃ to 45℃ (32°F to 113°F)
