Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Front Panel
Figure 1-5 Front Panel of RG-ES126S-LP
Note:
1. PoE overload LED
2. System status LED
3. Port status LED
4. PoE status LED
5. Port mode switch-over button
6. 10/100Base-TX auto-sensing Ethernet port
7. 10/100/1000Base-T auto-sensing Ethernet port
8. 10/100/1000Base-T combo port
Back Panel
Figure 1-6 Back Panel of RG-ES126S-LP
Note:
1. Grounding pole
2. AC power socket
Heat Dissipation
The RG-ES126S-LP adopts fans for heat dissipation, thereby ensuring normal function of the device in the specified
environment. 10 cm distance space should be reserved at both sides and the back plane of the cabinet to allow air
circulation. It is recommended to clean the device once every 3 months to avoid dust from blocking vents.
LEDs
LED
Panel Identification
State
Meaning
System status LED
PWR
Off
The switch is powered off.
Solid green
The switch is operational.
