Ruijie Reyee RG-ES100 Series - Page 8

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Storage
Temperature
-40℃ to 70℃ (-40°F to 158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Port Mode
Support switchover in three modes:
1. Flow Control On
2. Flow Control Off
3. Port Isolation. When this mode is enabled, ports 1-24 are isolated from each other, but can
communicate with ports 25, 26 and 26F.
Fan
Supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
EMC Standards
GB9254-2008
EN 55032:2015
EN 55035:2017
EN IEC61000-3-2:2019
EN 61000-3-3:2013
Draft ETSI EN 300 386 V2.2.0 (2020-10)
Security Standards
GB4943-2011
EN 62638-1
Earth Leakage
Current
≤ 1.5mA
Dimensions
(W x D x H)
440 mm x 208 mm x 44 mm (17.32 in. x 8.19 in. x 1.73 in.)
Weight
(With Package)
3 kg (6.61 lbs)
The RG-ES126S-LP switch is a class A product. In a domestic environment, this product may cause radio interference
in which case the user may be required to take adequate measures.
Product Appearance
RG-ES126S-LP provides 24 10/100Base-TX auto-sensing Ethernet ports, 2 10/100/1000Base-T auto-sensing Ethernet
ports, a 1000Base-X SFP port, system status LEDs and a port mode switch-over button on the front panel, and a power
socket and a grounding pole on the back panel.
Figure 1-4 Appearance of RG-ES126S-LP
