Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
LED
Panel Identification
State
Meaning
System status LED
PWR
Off
The switch is powered off.
Solid green
The switch is operational.
RJ45 port status LED
Upper left corner of the
port
Off
The port is not connected.
Solid green
The port is connected at 10/100 Mbps.
Blinking green
The port is receiving or sending traffic at 10/100
Mbps.
RJ45 PoE status LED
Upper left corner of the
port
Off
PoE does not supply power.
Solid green
PoE is operational.
1.2 RG-ES126S-LP
Technical Specifications
Model
RG-ES126S-LP
Ports
Ports 1-24 are 10/100Base-TX auto-sensing Ethernet ports, and support PoE/PoE+
Ports 25 and 26 are 10/100/1000Base-T auto-sensing Ethernet ports, and do not support
PoE/PoE+
Port 26F is a 1000Base-X SFP port multiplexed with Port 26 as a combo port, and the SFP port
takes priority
Power Supply
 AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
Frequency: 50/60 Hz
Rated current: 4 A Max
EEE
Not supported
PoE
Support PoE and PoE+.
Ports 1-24 are PoE/PoE+-capable with the maximum power output of 30W per port. Ports 25-
26 do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 180W.
Power
Consumption
Less than 10W with no PoE load
Less than 220W with PoE full load
Operating
Temperature
0℃ to 45℃ (32°F to 113°F)
