Ruijie Reyee RG-ES100 Series

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Front Panel
Figure 1-8 Front Panel of RG-ES110D-P
Note:
1. System status LED
2. Port status LED
3. PoE status LED
4. 10/100Base-TX PoE port
5. 10/100/1000Base-T auto-sensing Ethernet port
Back Panel
Figure 1-9 Back Panel of RG-ES110D-P
