Ruijie Reyee RG-ES100 Series

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Note:
1. Grounding pole
2. Port mode switch-over button
3. DC power socket
Heat Dissipation
The RG-ES110D-P adopts natural heat dissipation, thereby ensuring normal function of the device. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device. It is recommended to clean the device once every 3 months to avoid
dust from blocking vents.
LEDs
LED
Panel Identification
State
Meaning
System status LED
PWR
Off
The switch is powered off.
Solid green
The switch is operational.
RJ45 port status LED
Link/ACT (1-10)
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or sending traffic at
10/100/1000 Mbps.
RJ45 PoE status LED
PoE (1-8)
Off
PoE does not supply power.
Solid green
PoE is operational.
Blinking green
PoE is overloaded.
1.4 RG-ES118S-LP
Technical Specifications
Model
RG-ES118S-LP
Ports
16 10/100Base-TX auto-sensing Ethernet ports (Auto MDI/MDIX), and support PoE/PoE+
2 1000Base-X SFP combo ports
Power Supply
 AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
