Ruijie Reyee RG-ES100 Series

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Frequency: 50/60 Hz
Rated current: 2.5 A
EEE
Port 1-16: Supported
Port 17-18: Not Supported
PoE
Support PoE and PoE+.
Ports 1-16 are PoE/PoE+-capable with the maximum power output of 30W per port. Ports 17-
18 do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 120W.
Power
Consumption
Less than 13W with no PoE load
Less than 148W with PoE full load
Operating
Temperature
0℃ to 45℃ (32°F to 113°F)
Storage
Temperature
-40℃ to 70℃ (-40°F to 158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Port Mode
Support switchover in three modes:
1. Flow Control On
2. Flow Control Off
3. Port Isolation. When this mode is enabled, ports 1-16 are isolated from each other, but can
communicate with ports 17 and 18.
Fan
Not supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
EMC Standards
GB9254-2008
EN 55032:2015
EN 55035:2017
EN IEC61000-3-2:2019
EN 61000-3-3:2013
Draft ETSI EN 300 386 V2.2.0 (2020-10)
Security Standards
GB4943-2011
EN 62638-1
Earth Leakage
Current
≤ 1.5mA
Dimensions
(W x D x H)
440 mm x 208 mm x 44 mm (17.32 in. x 8.19 in. x 1.73 in.)
Weight
(With Package)
3.40 kg (7.50 lbs)
The RG-ES118S-LP switch is a class A product. In a domestic environment, this product may cause radio interference
in which case the user may be required to take adequate measures.
Product Appearance
