Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Port Mode
Support switchover in three modes:
1. Flow Control On
2. Flow Control Off
3. Port Isolation. When this mode is enabled, ports 1-4 are isolated from each other, but can
communicate with ports 5-6.
Fan
Not supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
EMC Standards
GB9254-2008
EN 55032:2015
EN 55035:2017
EN IEC61000-3-2:2019
EN 61000-3-3:2013
Draft ETSI EN 300 386 V2.2.0 (2020-10)
Security Standards
GB4943-2011
EN 62638-1
Earth Leakage
Current
≤ 1.5mA
Dimensions
(W x D x H)
100 mm x 100 mm x 26 mm (3.94 in. x 3.94 in. x 1.02 in.)
Weight
(With Package)
0.66 kg (1.46 lbs)
The RG-ES106D-P switch is a class A product. In a domestic environment, this product may cause radio interference
in which case the user may be required to take adequate measures.
Product Appearance
RG-ES106D-P provides 6 10/100Base-TX auto-sensing Ethernet ports on the front panel, and a port mode switch-over
button, a system status LED, a power socket and a grounding pole on the back panel.
Figure 1-1 Appearance of RG-ES106D-P
