RUiXU Lithi2-16 - Inverter Brand

Version: V1.0 Page
26
of 50
Link OUT
1
RS485-B2
Used to connect with
downward battery system
Link IN.
2
RS485-A2
3
SGND
4
CAN-H
5
CAN-L
6
PE
7
RS485-A2
8
RS485-B2
The BMS contains the CANBUS 120Ω resistance, and the BMS will automatically connect or
disconnect the resistance according to the need. It is not necessary to connect the 120Ω resistance
when connecting the CANBUS.
3.3.2 Inverter brand
Supported inverter brands
ID
CANBUS Connection
RS485 Connection
1
Victron/SMA/Studer Innotec/Sofar
Voltronic/RCT/MPP/
Alphaoutback
2
Sol-Ark/Solis/Goodwe/Deye/Growatt/SAJ /
Megarevo/INVT/Sermatec/TBB/MUST/Sunsynk/PYLON
SRNE
3
Schneider
PYLON
4
LUXPOWER
/
Note: Please refer to Appendix I for the communication connection method.
