MODEL 53515/53615/63515/63615/73515/73615
30
F. Series System
This is 2 or more than 2 valve systems, all in service, with one flow
meter for the entire system. For the time type valve, the regeneration
time should be set and adjusted to the Max; for the meter type valve,
connect its signal output connector with the remote handle connector of
the time type valve. That can realize the function of supplying water
simultaneously and regenerating orderly. The wiring refers to Figure
3-13.
3.3. System Configuration and Flow Rate Curve
A. Product Configuration
①. 63515/63615/73715/73615 softener valve configuration with tank, resin
volume, brine tank and injector.
The Minimum Salt
Consumption for
Regeneration（Kg）
