TECHNICAL SPECIFICATIONS
Dimensions: 17"W x 12"D x 3.5"H (43 x 30.5 x 9 cm)
Weight: 18 lbs. (8.1 kg)
Power Supply: 110 or 240 VAC
Fuse Rating: 110V input; F3A H 250V US and Canada
240V input; T1.25A H 250V Europe
Frequency Response: 20Hz-20kHz +/- 1dB
Watts per channel: 20 Watts RMS into 8 Ohms
THD+N: <0.05%
Signal to Noise Ratio: >88dB
Audio Source Inputs: 6 (including internal tuner)
Input Impedance: 50 kohm
Audio Zone Outputs: 6 Speaker Level (8 Ohms)
(2 Line Level)
Max Source Audio Input: 2.2 Vrms
Max Zone Variable Line Audio Output: 2.2 Vrms
Max Zone Fixed Line Audio Output: 2.2 Vrms
Trigger Outputs: 1 Common. 12VDC 100mA
Trigger Inputs: 1 Home Theater 12VDC max
Frequency Range: AM 530 - 1710 kHz
FM 87.7 - 107.9 MHz
Antenna impedance: AM: 300 Ohm balanced
Impedance: FM: 75 Ohm unbalanced
Sensitivity @ S/N: AM: 20dB 55dBu
FM: 30dB 6dB max 12dBu
Image rejection: AM: 33dB
FM: 80 DB
S/N ratio: AM: 45 dB
FM: 60 DB
