Russound SIX-SOURCE CONTROLLER CAM6.6 - UNO-TS2 Touchscreen

9
USER
COMPONENT GUIDE
UNO-TS2 Touchscreen
IR RECEIVER - Receives IR signals and passes them to the controller and source equip-
ment. Also used when operating the touchscreen by using the SRC2 remote
TOUCHSCREEN - Full color resistive touchscreen with multi-sound feedback. Screen
can be programmed to go blank after a period of inactivity. Touching the screen any-
where reactivates it.
PLUS - Adjust setting for selected source
MINUS - Adjust setting for selected source
NEXT - Go to next selection for selected source
PREVIOUS - Go to previous selection for selected source
POWER - Turn room power on/off. Press and hold for system all on/all off
PAUSE - Pause/mute for selected source
VOLUME DOWN - Adjust volume down for room controlled by touchscreen
VOLUME UP - Adjust volume up for room controlled by touchscreen
