27
OPTIONAL INTERNAL SOURCE - Factory installed optional internal source, AM/FM
radio module
AC 240V-AC 110V Switch - Switches A/C input voltage between 110VAC and
240VAC
AC 120/240 INPUT - Grounded 3-terminal plug detachable power cord connection
for the CAM6.6
FUSE HOLDER - Holds a replaceable fuse for A/C input connection
110VAC operation - F 3A H 250V, 240VAC operation; T 1.25A H 250V
SPEAKER OUTPUTS - Connect 8 Ohm speakers for each zone with detachable color-
coded modular snap connectors
AUDIO OUTPUTS - Audio line output connection
FIXED/VARIABLE SWITCH - Change line out between fixed and variable output.
COMMON IR OUTPUT - Output jack will pass all IR signals from all keypads
SOURCE IR OUTPUTS - Six source-specific IR Output jacks allow for IR control of
source equipment
AUDIO INPUTS - Six sets of Audio Line Level input connections for CAM6.6 source
components
OUTPUT/INPUT SWITCH - Enable Source Input 1 or enables Internal Source 1 output
20
19
18
17
16
15
14
13
12
10
11
INSTALLER
COMPONENT GUIDE
CAM6.6 Controller-Rear Panel
