INSTALLER

INSTALLATION MENU

9. SUFFIX CMD – Tells the system whether a command will be issued after the

(Sufix) selection of the numerical value (e.g., 1, 2

Enter

). If “no,” proce-

dure advances to SAVE CHANGES (step 13)

10. COMMAND TYPE – Select the type of source command (e.g., CD, TV, etc.).

(CmdTp)

a. Selected: Learned IR Choose Learned IR if the pre-programmed IR code library does

(LrnIR) not support the source component.

i. LEARNED SRC – Select the learned source bank to be assigned to the source

(LnSrc) component. Procedure advances to KEY FUNCTION (step 12)

b. Selected: Unassigned The numeric IR Suffix command is cleared. Procedure advances

(Unasg) to SOURCE NUM (step 1)

c. Selected: Default Default selects the same device type and device code previously

(Deflt) setup in BASIC SETUP. Procedure advances to KEY FUNCTION

(step 12)

d. Selected: Macro: (To build macros, see Macro Editor page 62)

(Macro)

i. MACRO - Macro loads a series of commands which are processed when

(Macro) activated.

ii. MACRO ID – Enter the macro ID number. Menu advances to SAVE CHANGES

(MacID) (step 13)

e. All Other Selections: Procedure advances to DEVICE CODE (step 11)

11. DEVICE CODE – Source component code for IR control.

(DevCd)

12. KEY FUNCTION – Select a function (Enter, Play, etc.).

(KeyFn)

13. SAVE CHANGES? – Select “yes” to save the changes.

(Save?)

SRC SEL CMD (SrcSC)

This procedure permits a command to be sent to the source component when the source component

is initially selected.

See Source Select Command & # Of Sources - Flow Chart on page 70

1. SOURCE NUM – Select the source number this command will be configured for.

(Src #)

(Continued next page)
