6.2. Serial Port Emulation
When connecting the LB2001 to the PC a serial port driver will be installed.
The following serial port settings must done.
RS-232 Settings
baud rate 9600
data bits 8
parity none
stop bit 1
flow control none
6.3. Serial Port Commands
The interface accepts 2 ASCII commands. Every command need a fixed number of
characters. A valid command will be echoed from the interface.
Read Parameter Command
Syntax
R
Response
Param0 Param2 … Param15
Description
Param0 = PI corner Frequency
Param1 = Low frequency gain limit
Param2 = Gain
Param3 = Span
Param4 = Low pass attenuator
Param5 = High pass attenuator
Param6 = Bias voltage high byte
Param7 = Bias voltage low byte
Param8 = Center voltage high byte
Param9 = Center voltage low byte
Param10 = low/high pass Polarity
Param11 = Lockstatus & Preatt.
Param12 = Error voltage high byte
Param13 = Error voltage low byte
Param14 = Integrator lvl high byte
Param15 = Integrator lvl low byte
