Sacher Lasertechnik LB2001 - Prepare for Use; Frontpanel Tour

Operation Manual LB2001 Sacher Lasertechnik
GmbH
_____________________________________________________________________________________________________
Adress:
Sacher Lasertechnik GmbH
Rudolf-Breitscheid-Str. 1-5
D-35037 Marburg, Germany
Tel.: +49 (6421) 305-0
Fax.: +49 (6421) 305-299
EMail: contact@sacher-laser.com
Web: http://www.sacher-laser.com
Sacher Lasertechnik, LLC
5765 Equador Way
Buena Park, CA 90620, USA
Tel.: 1-714-670-7605
Fax: 1-714-670-7662
Email: sales@sacher-
laser.com
Page 7
Version:
Preliminary 2011-01-01
3. Prepare for Use
This chapter gives an overview of the front panel controls and connectors of the LB2005
servo controller and gives all information that is necessary to put the instrument into operation
and connect external devices.
3.1. Frontpanel Tour
The front panel of the LB2005 consists of the 7 segment displays hardkeys and the
incremental rotation encoders.. Brief explanations on the controls rear panel can be found on
the next pages
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
I
J
K
