3.2. Rear Panel Tour
Input A (non inverting input), The error signal is generated from the voltage
(A – B) applied to the BNC input connector
USB Remote Interface.
Input B (inverting input), The error signal is generated from the voltage applied to the
BNC input connector
Output (LP): This low pass BNC output is the control signal from the proportional-
integral (P-I) filter, going to the filter section and summed with the sweep and
modulation signals.
1
2
3
4
5
6
7
8
9
A
B
C
D
