MANUAL OVERVIEW 4
1.1 Introduction 4
2.2 Vending machine intended use 4
2.4 Vending machine identification 5
2.5 Technical specifications 5
3-
4.1 General safety rules 6
4.2 Operator requirements 6
4.3 Installed safety devices 6
5-
INSTRUMENT COMMAND DESCRIPTION 7
6.1 List of accessory equipment 8
standard D.A. 5P types) 8
Machine with direct waterworks
Connection (D.A. 3P R.I.eD.A. 5P 8
R.I . types)
6.3 Electric connection 9
6.4 PARALLEL 12 V d.c coiner fitting 9
6.5 Clock module insertion 10
6.6 Nation key insertion 10
6.7 Serial port connection 10
6.8 Affixing labels and stickers 10
7-
7.1 Programming structure 12
7.3 Programming mode access 13
7.4 Selection of the parameter
to be changed or displayed 14
7.5 Changing and memory storing
parameters 14
7.6 Menu description 14
First main item of
the programming menu 14
Second main item of
the programming menu 17
Third main item of
8- VENDING MACHINE USE 22
8.3 Programmed automatic start up 22
8.4 Drink dispensing 22
8.5 First vending machine start up 22
Soluble product container
(only D.A. 5P) 22
Water tank 23
Coffee container 23
Operations to be performed
on the vending machine 23
Coin/token box 24
9.2 Cleaning and maintenance 27
Coffee unit 27
Mixer and dispenser (only D.A. 5P) 27
Soluble powder container 28
9.3 Mix fan replacement 28
11- VARIATIONS 28
11.1 D.A. 3P/5P model
(without clock module) 28
11.2 Programming structure
(V.M 3P standard version and
D.A. 5P standard without clock module)
