Saeco 3P - Water Tank

English
- Insert the soluble product without exceeding 2/3 of maxi
mum capacity.
- Close the cover and completely reinsert the container in
its seat.
Coffee container
Proceed in filling the coffee bean container:
- Pull the coffee container outward, lift the cover and fill the
container with coffee beans (fig. 21),
Water tank
Proceed in filling the water tank (except for the versions with
direct waterworks connection).
- Disconnect the tube (ref. A, fig. 19) from the tank by acting
on the automatic coupling.
- Extract the tank from its seat by slightly ifting the handle
(fig.19).
- Unscrew the ring nut, extract the valve and fill the tank with
fresh drinkable water.
- Reinsert the valve in the hole making sure that the
aspiration tube (ref. B, fig. 20) is inserted inside the tubular
handle, and re-screw the ring nut.
Grinding adjustment
Adjust the coffee grinding indicator on one of the following
values by turning the knob (fig. 22):
Italy…………………………….4-7
Spain………………………….5-8
France – Switzerland………..5-8
Germany – Austria…………..6-9
USA-Canada…………………6-14
Insert the required token (or coins) in the slot, press the
button corresponding to coffee dispensing and check
product quality. If coffee is dispensed too slowly, it's
necessary to adjust grinding on a higher value; if on the
contrary coffee is dispensed too fast, place the indicator on
a lower grinding value.
Warning
Once grinding has been adjusted it's necessary to
dispense at least two coffees to notice the difference.
Operations to be performed on the vending
machine
- Enable electric functions (main switch in the "I" position).
Fill the vending machine water circuit according to the
following procedure:
- Open the door
- Insert the key (ref. 30, fig. 23) in the safety micro-switch
operation opening (ref, 31, fig. 23),
23
