MAIN PARTS
Mod. LUXE / Mod. COFFEE / Mod. CAPPUCCINO / Mod. CAPPUCCINO USA
1 Left panel
15
Door
2 Cup shield
16
Coffee grounds drawer
3 Rear panel
17
Steam wand (except for COFFEE set-up)
4 Cup warming surface 18 Power button
5
Pre-ground coffee door (except for CAPPUCCINO USA set-up)
“I” Electrical functions enabled - Machine on - Indicator light on.
6 Right coffee bean hopper
“O” Electrical functions disabled - Machine off - “I” button indicator
light off.
7 Right panel
19
Right grinder adjustment knob
8 Control panel
20
Right coffee grinder group
9 Rubber grip 21 Mechanical pulse counter
10 Hose clamp (CAPPUCCINO set-up) It displays the number of beverages brewed by the machine.
11 Hot water wand (except for COFFEE set-up)
22
Brew group
12 Steam dispensing knob (except for COFFEE set-up)
23
Brew group cover
Clockwise:
Steam jet open
24
Milk froth adjustment (CAPPUCCINO set-up)
Counter-clockwise:
Steam jet closed
25
Temperature adjustment (CAPPUCCINO set-up)
13 Drip tray
26
Milk dispensing spout (CAPPUCCINO set-up)
14 Anti-scald steam wand rubber
27
Brew group
