SAES NEG POWER - Page 33

M.HIST.0101.23 R2 Page 33 of 36 January, 26
th
2021
GP100 MK5, GP200 MK5, GP500 MK5,
CapaciTorr D2000, CapaciTorr D3500
For these pumps which are equipped with a dedicated electrical connector, use the output supply
cable shown in figure:
A
D
C
F
B
E
BLUE
BROWN
NEGATIVE - GREEN
POSITIVE - RED
YELLOW/GREEN
2
1gnd
3
5
YELLOW/GREEN
BLUE
BROWN
NEGATIVE GREEN
POSITIVE RED
TO NEG PUMP CONTROLLERTO GETTER PUMP
REAR VIEW OF CONNECTORS
CapaciTorr D400-2
For these pumps which are equipped with a dedicated electrical connector, use the output supply
cable shown in figure:
Yellow/green
Brown
A
D
C
B
Blue
21
gnd
3
5
Yellow/Green
Blue
Brown
TO NEG PUMP CONTROLLER
REAR VIEW OF CONNECTOR
TO GETTER PUMP
