Sage SIP - Terminal Hookup Prime Integral (Series SIP)

S A G E M E T E R I N G , I N C .
O p e r a t i o n s a n d I n s t r u c t i o n M a n u a l
18
REV. 16-SIP/SRP
Prime Integral (Series SIP)
SEE “WIRING” ON PAGE 10 FOR INSTRUCTIONS ON HOW TO REMOVE REAR LID;
SEE FOLLOWING PAGES FOR TERMINAL HOOKUP
1 RED AC1 COM 1
2
S1 AC2 B + 2
3
RED SPARE A – 3
4
WHITE 4-20mA PWR 4
5
S2 4-20mA 5
6
WHITE VDC GND 6
A B C
24 VDC
P
ULSE
VDC IN
+
VDC GND
–
INTEGRAL
INSIDE COVER VIEW INSIDE BODY VIEW
1/2" NPT
User Entry
for Wiring
3/4" NPT for
Probe Support
NO CUSTOMER ACCESS
DO NOT OPEN THIS SIDE
DISPLAY SIDE
1/2" NPT
View Entry
(ONE ON EACH SIDE)
FLOW
TERMINAL BLOCK SIDE
