Sage SIP - Drawings In-Line and Insertion Flanges

UPSTREAM
F
L
O
W
S A G E M E T E R I N G , I N C .
O p e r a t i o n s a n d I n s t r u c t i o n M a n u a l
40
REV. 16-SIP/SRP
Flanged Ends for
In-Line Meter (OPTIONAL)
Flanges for 3
1
⁄2" pipe sizes and up,
have 8 bolt holes
Flanges for 3" pipe sizes and
smaller have 4 bolt holes
Flanged Mounting for
Insertion Meter (OPTIONAL)
