O p e r a t i o n s a n d I n s t r u c t i o n M a n u a l
31
S A G E M E T E R I N G , I N C .
REV. 16-SIP/SRP
HAZARDOUS LOCATION APPROVALS
All 24 VDC Powered Sage Prime Meters (SIP Integral
I
nsertion, SIP In-Line, SRP Remote Insertion, SRP
Remote In-Line) are approved for Class 1, Div 2,
Groups B, C, D, T4 and ATEX: Ex nA IIC T4.
AC Powered Meters are not approved.
Testing is in accordance with the following Safety
Standards:
• UL1604, Third Edition, Electrical Equipment for
Use in Class I and II, Division 2, and Class III
Hazardous (Classified) Locations
• CSA C22.2 No. 213-M1987 (R1999), First Edition,
Non-incendive Electrical Equipment for Use in
Class I, Division 2 Hazardous Locations
• UL/CSA 61010-1, Second Edition, Safety Require -
ments for Electrical Equipment for Measurement,
Control, and Laboratory Use – Part 1: General
Requirements
The following is required to comply with the above
mentioned Approvals
1) Repair of the product (or replacement of compo-
nents) is not possible by the user
2) As noted on the following label (see below) it will
contain the following markings: Ex symbol, nA
symbol IIC, temperature class
3) All Prime DC meters will be marked with “X”
which means that these Special Conditions of
Use will apply:
a) The completed meter must be installed with a
rigid or flexible metal conduit in order to satis-
fy approval conditions.
b) The meter has been approved for use with the
electronics enclosure in an ambient tempera-
ture from –20˚C < Ta < 65˚C.
4) Sage Metering considers a linear correction suit-
able for temperatures exceeding the temp code
rating of 40C (104F) thus no customer correction
is needed.
CONFORMANCE
All AC & DC Powered Sage Metering, Inc. Series
SIP (Sage Prime-Integral) and Series SRP (Sage Prime-
Remote) are CE Compliant for the following CE
directives:
• EN61000-6-4 for Electromagnetic compatibility;
• EN61000-3-2 for Harmonics;
• EN61000-3-3 for Flicker;
• EN61000-6-2 for Electromagnetic Compatibility
(Immunity for Industrial Environments), which
includes EN61000-4-2 for ESD;
• EN61000-4-3 for Radiated Immunity;
• EN61000-4-4 for EFT/B; EN61000-4-5 for Surge;
• EN61000 for Conducted Immunity;
• EN61000-4-8 for Magnetic Immunity;
• EN61000-4-11 for Voltage Interruptions
MEDICAL CONFORMANCE
Contact Sage Metering if Medical CE Conformance
is required. (AC Powered Sage Prime Meters only.)
The Standard is to IEC 60601-1-2:2007 Edition 3
Approvals
S
AGE METERING, INC.-MTRY, CA 93940/ PRIME THERMAL MFM
Class I, Div 2, Groups B,C,D T4 ATEX: Ex nA IIC T4 X
MODEL #
SERIAL # mW0 =
FOR USE IN HAZARDOUS LOCATIONS–CAUTION–DISCONNECT FROM POWER
S
UPPLY BEFORE OPERATING. KEEP COVER TIGHT WHILE CIRCUITS ARE ALIVE.
CONDUIT SEALS MUST BE INSTALLED WITHIN 18˚ OF THE ENCLOSURE.
ATTENTION–OUVRIR LE CIRCUIT AVANT
D’ENLEVER LE COUVERCLE GARDER
L
E COUVERCLE BIEN FERME TANT QUE LES CIRCUITS SONT SOUS TENSION.
UN SCELLEMENT DOIT ETR INSTALLE A MOINS DE 45CM DU BOITER.
