34
3270360_GB
CONDENSING SYSTEM MAINTENANCE
Mod. …31… - …41… - …51… - …101
… - …141… - …171…
To access the condensing
system, remove the rear protective gril
le, undoing the
screws.
Mod. …351H
To access the condensing
system, remove the side panel, undoing the screws.
33
35
