WIRING DIAGRAM PLATE
The electrical diagram is shown on the last page of the booklet.
N° DESCRIPTION N° DESCRIPTION
1
COMPRESSOR
72
ELECTRONIC DATA CARD LCD
2
CONDENSER FAN
73
FUSE-HOLDER WITH UNIPOLAR FUSE
2A
THERMOSTATED CONDENSER FAN
75
ELECTROVALVE
3
GENERAL TERMINAL BOARD
76
MAGNETIC MICRO-SVWITCH
3A
GENERAL TERMINAL BOARD
77
COMPARTMENT PROBE
3B
GENERAL TERMINAL BOARD
78
EVAP./DEFROST PROBE
9
EVAPORATOR FUN
79
NEEDLE CORE PROBE
20
DOOR ANTICONDENSING RESISTOR
79A
MULTIPOINT NEEDLE CORE PROBE
21
DEFROST RESISTANCE
79B
MULTIPOINT PROBE RESISTANCE
21A
DEFROST RESISTANCE
80
PTC RESISTANCE FOR COMPRESSOR CASING
25
TRANSFORMER
86
CONDENSER PROBE
44
RELAY COMPRESSOR
87
LCD QUICK COOLER CARD
65
CONTACTOR
97A
EVAP. FAN CHOKE MODULE
66
THERMAL RELAY
102
BIMETALLIC SAFETY THERMOSTAT
67
EVAPORATOR FAN RUN CAPACITOR
122
LED LAMPS
67A
EVAPORATOR FAN RUN CAPACITOR
127
RGB CONTROLLER
69
GROUNDING TERMINAL
128
USB ADAPTER
70
HIGH PRESSURE PRESSOSTAT
129
ENCODER ADAPTER
71
POWER PANEL ELECTRONIC CARD
132
LED DISPLAY ELECTRONIC BOARD
